서버가 필요없는AI 영상분석 장비
iSpur Hardware J100
ServerlessAI Image AnalysisEquipment
iSpur Hardware J100
Not only homes and offices, but also commercial spaces! Experience it in a variety of environments.
iSpur Hardware J100
Overview
AI Video Analysis Without Servers
The iSpur Hardware is a high-performance AI processing device designed for real-time AI video analysis in edge environments. It allows for easy connection of various cameras and IoT devices, enabling local analysis and event control without network interruptions. The device operates independently without the need for cloud services, making it suitable for various applications in industrial sites, security, traffic, and safety management.
Key Features
High-performance edge AI processing capabilities
- NVIDIA Jetson Orin (various AI accelerator options available in the future)
- Multi-channel simultaneous decoding and AI inference
- Real-time execution of various AI models, including object detection, area intrusion, and behavior analysis.
Edge computing-based independent AI analytics
- Perform all functions locally, from AI inference to event processing and storage, without servers or clouds.
- Real-time on-site analysis with immediate response without transmission delays
- Stable operation even in external network disconnection situations
Various interfaces and connectivity
- Provides abundant I/O ports including USB, RS-485, DI/DO, and GPIO
- Supports connection to various IP cameras based on ONVIF and RTSP.
- IoT/industrial equipment integration possible with MQTT, Modbus, Webhook, etc.
Network separation configuration
- Network separation by purpose, such as camera network, internal network, and control network, is possible.
- Building a stable communications infrastructure even in security-critical industrial settings.
- Supports role separation and VLAN configuration for each port
Equipped with AI video analysis platform
- Our AI video analysis platform is pre-installed and ready to use right away.
- Integrated management including automatic camera registration, AI model setup, and event rule setup.
- Includes real-time dashboards, AI search, and action handlers.
Robust design for industrial environments
- Stable operation even in extreme temperatures ranging from -20°C to 60°C
- Minimizes maintenance burden with dust-proof, fanless design
- Supports flexible installation methods such as DIN rail and wall mounting
Specifications
AI accelerator
NVIDIA Jetson Orin NX
Network
2 x 2.5GbE, 1 x GbE
USB
4 x USB 3.1, 1 x Type C
USB 2.0 (OTG)
Digital I/O
4DI / 4DO
Serial Port, CANBus
2 x RS232/RS422,
1 x CANBus
Storage
NVMe 128GB
Operating temperature
-20°C ~ 60°C
Size / Weight
173W x 130D x 85H mm
/ 2.6kg
Mounting
DIN Rail, VESA, Wall
Power
DC 9 ~ 36V
Utilizing
AI-managed buildings
AI for Warehouses
Safe and efficient parking lots powered by AI
Efficient store management with AI
FAQ
Yes, complete local analysis is possible from video collection, AI analysis, and event processing without the Internet.
Yes, updates are available via OTA.
